Coleman TH4B4223S - Page 161

5523951-CTG-J-0620
Johnson Controls Ducted Systems 161
Multipliers for determining the performance with other indoor sections.
CP9C120D20MP12C CF/CM/CU48D 1.00 1.04 0.92
CP9C120D20MP13C CF/CM/CU48D 1.00 1.04 0.92
CPLC080B12MP12C CF/CM/CU48C 1.00 1.05 0.96
CPLC080B12MP13C CF/CM/CU48C 1.00 1.05 0.96
CPLC080C16MP12C CF/CM/CU48C 1.00 1.08 0.93
CPLC080C16MP12C CF/CM/CU48D 1.00 1.03 0.92
CPLC080C16MP13C CF/CM/CU48C 1.00 1.08 0.93
CPLC080C16MP13C CF/CM/CU48D 1.00 1.03 0.92
CPLC100C16MP12C CF/CM/CU48C 1.00 1.08 0.93
CPLC100C16MP12C CF/CM/CU48D 1.00 1.03 0.92
CPLC100C16MP13C CF/CM/CU48C 1.00 1.08 0.93
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. KW
CPLC100C16MP13C CF/CM/CU48D 1.00 1.03 0.92
CPLC100C20MP12C CF/CM/CU48C 1.00 1.08 0.92
CPLC100C20MP12C CF/CM/CU48D 1.00 1.08 0.92
CPLC100C20MP13C CF/CM/CU48C 1.00 1.08 0.92
CPLC100C20MP13C CF/CM/CU48D 1.00 1.08 0.92
CPLC120C20MP12C CF/CM/CU48C 1.00 1.08 0.92
CPLC120C20MP12C CF/CM/CU48D 1.00 1.08 0.92
CPLC120C20MP13C CF/CM/CU48C 1.00 1.08 0.92
CPLC120C20MP13C CF/CM/CU48D 1.00 1.08 0.92
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. KW
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO TH4B3622S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
AIR TEMP.
ENTERING
INDOOR COIL (°F)
ID CFM
1000 1200 1400
MBH COP KW MBH COP KW MBH COP KW
60
60 40.6 4.12 2.88 41.2 4.26 2.83 41.8 4.40 2.78
70 39.9 3.70 3.19 40.4 3.84 3.12 41.0 3.98 3.05
80 39.1 3.27 3.50 39.7 3.42 3.41 40.2 3.56 3.31
47
60 35.3 3.73 2.77 35.9 3.86 2.73 36.5 3.99 2.68
70 34.8 3.34 3.08
35.3 3.46 3.03 35.8 3.57 2.97
80 34.3 2.96 3.40 34.7 3.06 3.33 35.0 3.15 3.25
40
60 33.2 3.55 2.74 33.5 3.64 2.70 33.8 3.72 2.66
70 32.5 3.17 3.04 32.9 3.26 2.99 33.3 3.35 2.94
80 31.9 2.79 3.34 32.3 2.89 3.28 32.8 2.99 3.22
30
60 28.2 3.11 2.66 28.9 3.20 2.64 29.5 3.30 2.62
70 27.9 2.80 2.96 28.5 2.89 2.92 29.0 2.97 2.89
80 27.6 2.49 3.25 28.1 2.57 3.20 28.5 2.65 3.15
17
60 23.1 2.66 2.55 23.2 2.69 2.53 23.4 2.72 2.51
70 22.5 2.36 2.82 22.7 2.40 2.80 22.9 2.44 2.79
80 21.8 2.06 3.10 22.1 2.11 3.08 22.4 2.15 3.06
10
60 19.5 2.25 2.54 19.8 2.28 2.55 20.2 2.31 2.55
70 19.4 2.07 2.76 19.8 2.10 2.77 20.1 2.13 2.78
80 19.4 1.90 2.99 19.7 1.92 3.00 20.0 1.95 3.01
0
60 16.0 1.92 2.43 16.3 1.94 2.44 16.6 1.97 2.45
70 16.0 1.77 2.65 16.3 1.79 2.66 16.5 1.82 2.67
80 16.0 1.62 2.87 16.2 1.64 2.87 16.4 1.66 2.88
-10
60 12.0 1.47 2.38 12.2 1.49 2.39 12.4 1.51 2.39
70 12.0 1.35 2.59 12.2 1.37 2.60 12.4 1.39 2.61
80 11.9 1.24 2.80 12.1 1.26 2.81 12.3 1.27 2.82
-20
60 7.9 0.99 2.32 8.1 1.01 2.33 8.2 1.02 2.33
70 7.9 0.92 2.53 8.0 0.93 2.53 8.2 0.94 2.54
80 7.9 0.84 2.73 8.0 0.85 2.74 8.1 0.86 2.75
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Yellow shaded cells are AHRI High Heating conditions.
Orange shaded cells are AHRI Low Heating conditions.
