Coleman TH4B4223S - Page 5

5523951-CTG-J-0620
Johnson Controls Ducted Systems 5
SYSTEM CAPACITY - Single Piece and Modular Air Handlers
UNIT
MODEL
AIR HANDLER
COIL
MODEL
3
RATED
CFM
COOLING
1
HEATING
2
MODEL WIDTH
NET MBH
SEER EER
NET MBH
HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
TH4B1821S AE18BBA21 17.5 – 675 18.0 14.6 15.75 13.00 18.0 11.5 9.00 7.45 3.88 2.60
TH4B1821S AE18BX21 17.5 – 600 18.0 13.6 15.25 12.75 17.6 11.7 8.75 – 3.78 2.56
TH4B1821S AE24BBA21 17.5 – 675 18.0 14.6 15.75 13.00 18.0 11.5 9.00 7.40 3.90 2.60
TH4B1821S AE24BX21 17.5 – 675 18.0 14.6 15.75 13.00 18.0 11.5 9.00 7.40 3.90 2.60
TH4B1821S AP18BBA21 17.5 – 600 18.0 12.8 14.00 12.00 18.2 12.1 9.00 7.65 3.52 2.38
TH4B1821S AP18BX21 17.5 – 600 18.0 12.8 14.00 12.00 18.2 12.1 9.00 7.65 3.52 2.38
TH4B1821S AP24BBA21 17.5 – 600 18.0 13.6 14.00 12.00 18.0 12.0 8.20 – 3.54 2.42
TH4B1821S AP24BX21 17.5 – 600 18.0 13.6 14.00 12.00 18.0 12.0 8.20 – 3.54 2.42
TH4B1821S AVC18BX21 17.5 – 650 18.0 14.4 15.75 13.00 18.0 11.5 9.00 7.50 3.82 2.58
TH4B1821S AVC24BX21 17.5 – 650 18.0 14.4 15.75 13.00 18.0 11.5 9.00 7.45 3.88 2.58
TH4B1821S ME08BN21 17.5 CF/CM18B 575 18.0 13.6 15.75 13.00 18.0 11.6 9.00 7.60 3.68 2.54
TH4B1821S ME08BN21 17.5 CF/CM24B 575 18.0 13.5 15.75 13.00 18.0 11.6 9.00 7.50 3.76 2.54
TH4B1821S ME08BN21 17.5 CF18BBAA1 600 18.0 13.6 15.00 12.75 17.3 11.7 9.00 – 3.80 2.56
TH4B1821S ME08BN21 17.5 CF24BBAA1 575 18.0 13.5 15.75 13.00 18.0 11.6 9.00 7.50 3.76 2.54
TH4B1821S ME08BN21 17.5 CM24BBAA1 600 18.0 13.6 15.25 12.75 17.5 11.7 9.00 – 3.84 2.60
TH4B1821S ME12BN21 17.5 CF/CM18B 675 18.0 14.6 15.75 13.00 18.0 11.5 9.00 7.45 3.88 2.58
TH4B1821S ME12BN21 17.5 CF/CM24B 675 18.0 14.6 15.75 13.00 18.0 11.5 9.00 7.40 3.90 2.60
TH4B1821S ME12BN21 17.5 CF18BBAA1 675 18.0 14.6 15.75 13.00 18.0 11.5 9.00 7.45 3.88 2.58
TH4B1821S ME12BN21 17.5 CF24BBAA1 675 18.0 14.6 15.75 13.00 18.0 11.5 9.00 7.40 3.90 2.60
TH4B1821S ME12BN21 17.5 CM24BBAA1 600 17.8 13.3 14.00 12.00 17.5 12.0 8.5 – 3.60 2.44
TH4B1821S MVC08BN21 17.5 CF/CM18B 625 18.0 14.1 15.75 13.00 18.0 11.5 9.00 7.45 3.86 2.56
TH4B1821S MVC08BN21 17.5 CF/CM24B 650 18.0 14.4 15.75 13.00 18.0 11.5 9.00 7.40 3.88 2.58
TH4B1821S MVC08BN21 17.5 CF18BBAA1 550 17.8 13.0 15.00 12.75 17.3 11.7 8.75 – 3.72 2.54
TH4B1821S MVC08BN21 17.5 CF24BBAA1 650 18.0 14.4 15.75 13.00 18.0 11.5 9.00 7.40 3.88 2.58
TH4B1821S MVC08BN21 17.5 CM24BBAA1 575 18.0 13.6 15.25 12.75 17.5 11.6 9.00 – 3.86 2.60
TH4B1821S MVC12CN21 21.0 CF/CM24C 650 18.0 14.4 15.75 13.00 18.0 11.4 9.00 7.40 3.92 2.60
TH4B2421S AE24BBA21 17.5 – 675 24.0 17.6 15.75 13.00 24.0 14.8 8.50 7.15 3.60 2.42
TH4B2421S AE24BX21 17.5 – 675 24.0 17.6 15.75 13.00 24.0 14.8 8.50 7.15 3.60 2.42
TH4B2421S AE30BX21 17.5 – 750 24.0 17.5 15.75 13.00 24.0 14.9 9.50 7.95 4.00 2.72
TH4B2421S AP24BBA21 17.5 – 800 23.8 17.0 14.00 11.75 24.0 15.4 8.55 7.40 3.50 2.32
TH4B2421S AP24BX21 17.5 – 800 23.8 17.0 14.00 11.75 24.0 15.4 8.55 7.40 3.50 2.32
TH4B2421S AP30BX21 17.5 – 800 24.0 18.5 15.25 12.25 24.0 15.6 8.50 – 3.80 2.54
TH4B2421S AVC24BX21 17.5 – 650 24.0 17.2 15.50 13.00 24.0 14.8 8.50 7.20 3.54 2.42
TH4B2421S AVC30BX21 17.5 – 800 24.0 18.0 16.00 13.00 24.0 15.0 9.50 7.95 4.02 2.72
TH4B2421S ME08BN21 17.5 CF/CM24B 800 24.0 19.4 15.75 13.00 24.0 14.8 8.75 7.35 3.74 2.44
TH4B2421S ME08BN21 17.5 CF/CM30B 800 24.0 18.0 15.75 13.00 24.0 15.0 9.50 7.95 4.02 2.72
TH4B2421S ME08BN21 17.5 CF24BBAA1 800 24.0 19.4 15.75 13.00 24.0 14.8 8.75 7.35 3.74 2.44
TH4B2421S ME08BN21 17.5 CF30BBAA1 800 24.0 18.7 16.00 13.00 23.8 15.3 8.50 – 3.98 2.68
