I/O shield does not fit into the chassis, you would need to obtain the proper
size from the chassis supplier.
Securing the Motherboard into the Chassis
Most computer chassis have a base with mounting studs or spacers to allow
the mother board to be secured to the chassis and help to prevent short
circuits. If there are studs that do not align with a mounting hole on the
motherboard, it is recommended that you remove that stud to prevent the
possibility of a short circuit.
1. Carefully place the motherboard onto the studs/spacers located inside
the chassis.
2. Align the mounting holes with the studs/spacers.
3. Align the connectors to the I/O shield.
4. Ensure that the fan assembly is aligned with the chassis vents according
to the fan assembly instruction.
5. Secure the motherboard with a minimum of eight-to-ten screws.
5-2-2 Connecting header and Setting Switches
This section takes you through all the connections and switch settings
necessary on the motherboard. This will include:
Power Connections
¾
24-pin ATX power
¾
4-pin ATX 12V power
Internal Headers
¾
Front panel
¾
USB Headers
¾ Audio
Serial ATA III
Chassis Fans
Rear panel USB 2.0 Adapter
Expansion slots
33
Ｈａｒｄｗａｒｅ Ｉｎｓｔａｌｌａｔｉｏｎ
