ADJUSTMENTS
AND
TESTING
SIMPLA 50B-BT
SIMPLA 55BT
SIMPLA 65BT
SIMPLA 50BST
Doc. 10021896
Issued 09/2010
Ver. AB
Page 14 of 16
8. Check the solution emerges due to gravity only (i.e. the
dosing system is not activated) when the tap lever is in the
position shown in the photo (central
).
Check the functioning and connections of the water and detergent
pumps.
Check the solution tubes are clean and in good condition.
Adjusting the squeegee
1. Adjust the inclination of the rear rubber, with the suction
motor ON, so it is even.
2. Use the special handwheel to adjust the height of the
wheels, checking the rubber inclination is between 30° and
45° and is even across its entire length.
About 30° - 45°
Rear rubber
Front rubber
