Huawei MA5680T Configurations
(1) Create VLAN
MA5680T(config)#vlan 10 smart
(2) Configure uplink port’s VLAN
MA5680T(config)#port vlan 10 0/19 1
MA5680T(config)#interface giu 0/19
MA5680T(config-if-giu-0/19)#native-vlan 1 vlan 10
(3) Configure DBA profile
MA5680T(config)#dba-profile add profile-id 12 profile-name 1GE type3 assure 102400 max 899968
(4) Configure line profile
MA5680T(config)#ont-lineprofile epon profile-id 11 profile-name 1GE
MA5680T(config-epon-lineprofile-11)#llid dba-profile-id 12
MA5680T(config-epon-lineprofile-11)#commit
(5) Configure service profile
MA5680T(config)#ont-srvprofile epon profile-id 6 profile-name 1GE
MA5680T(config-epon-srvprofile-6)#ont-port eth 1
MA5680T(config-epon-srvprofile-6)#commit
(6) Authorize ONU
MA5680T(config)#interface epon 0/5
MA5680T(config-if-epon-0/5)#ont add 1 0 mac-auth 002A-8523-C610 oam ont-lineprofile-id 11
ont-srvprofile-id 6
(7) Configure service-port
MA5680T(config)#service-port 27 vlan 10 epon 0/5/1 ont 0 multi-service user-vlan 10
(8) Configure ONU bridge mode by ONU web
4.1.2.2 Route mode for Internet service
1) Add a WAN connection
Choose “Network > WAN > WAN Connection” in navigation menu. Add a route mode WAN
connection as the following Parameter.
 New connection name is INTERNET.
