9
Parametric/Functional Tests covering: line regulation, calibration, linearity, burn-in, over-
temp test, open circuit test, MAX power test, harmonic distortion, AC ripple, and remote
interface tests. Data sheet for each generator to be shipped with unit.
E. Packaging & Shipping Specifications
1. Accessories Supplied
1.1 Final test results
1.2 Operating manual
2. Shipping
NOTE: If there is a conflict between this document and customer Purchase Order then the latter
supersedes.
NOTE FOR REPAIRS: Unless repairs have accessories included with them and have them listed on
the Return Material Authorization (RMA) Tag, returned materials will not have to fulfill procedural
requirements for accessories.
III. Unpacking and Inspection
1. Carefully unpack the unit and inspect for any obvious signs of physical damage that might have
occurred during shipment. Notify the shipping agent of any damage immediately.
2. Check the outside of the unit for missing or loose mounting screws or broken parts.
3. If there is shipping damage or the unit fails to operate properly upon receipt, report damage to the
carrier and Comdel immediately.
CAUTION: Breaking the seal or removing the warranty decal from this unit will void the warranty. If
internal damage is suspected, contact factory for assistance.
IV. Maintenance
The CLF5000/PLL is designed to run unattended for long periods of time. Should service be required, the system is
designed for quick repair. The whole RF section could be replaced in under sixty minutes.
After a time, scale may build up on the inside of the cooling tubes. This could greatly reduce the cooling capacity of
the system. It is recommended that the system be flushed with a descaling agent. A cleaning agent that does not
damage copper, stainless-steel, nickel or nylon tubing should be chosen.
A. RF Output Calibration Check
The CLF5000/PLL comes pre-calibrated from the factory and does not require any further adjustment. If
you must check the calibration of the CLF5000/PLL, use the following procedure:
WARNING: Qualified personnel only should perform Calibration. Improper procedures could damage the unit or
cause serious injury. There are no user adjustments inside the generator. Never operate this unit with the covers
removed. Any calibration discrepancies should be reported immediately to Comdel customer service. Trained
Comdel technicians may only make corrective adjustments to this unit.
