Comel COMPACTA INOX - Component Parts

R I C A M B I
DESCRIPTION
COMPONENT PARTS
721PAB-GABIRON
TYPE
LAST CHANGEDATE
VIEWREF.
21/03/2008
IFER-0020
N.B. Theaboveviewisapureindication.Itservestoshowall
thecomponentpartsoftheunittomakeanyserviceeasier.
A0028
A023C
A025A
A028A
D0002
D0004
D0007
D0009
D009A
D0010
D0013
D0018
D0020
D0034
G0001
G0002
G0006
G0007
G0008
G0010
G0011
G0015
G0016
G0017
G0018
G0020
G0021
G0022
R0221
R0709
R0740
Steamhose
Rubbersleeve
Thermostat
Steamhoseclamp
Steamhoseelbow
Screw
Junctionbox
Smallchromium-platedcover
Bigchromium-platedcover
Chromium-platedhandle
Corkhandle
Thermostatknob
Flex
Microswitchcore
Smallironbase
Bigironbase
Thermalcut-out
Markettag
Heatingelement
Wire
Wire
Backcap
Spacingcylinder
Screw
Backhandlesupport
Fronthandlesupport
Frontcap
Microswitchholder
Spacingtag
Bluemicroswitchbutton
Washer
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
*PIECESPERUNIT (IN THISVIEW)
REF.DESCRIPTIONQ*
G0008
G0001
G0002
D0002
G0011
D0004
R0221
R0709
D0009
D009A
D0010
G0010
A028A
G0006
A025A
G0007
D0018
D0007
G0015
A023C
D0020
G0016
G0020
G0022
D0034
G0021
G0018
G0017
D0013
R0740
A0028
