Technical specifications
GENERAL DATA
Type Modular
Product height (mm) 90
Product width (mm) 100
Product depth (mm) 35
Product colour Aluminium
Material Polycarbonate, Anodised aluminium
Flush mounting Yes, with specific accessory
Surface mounting Yes, with specific accessory
COMPATIBLE SYSTEMS
Simplebus 2 audio/video with power supply unit art. 4888C Yes
Simplebus 2 audio/video with power supply unit art.
1210/1210A
Yes
Simplebus 2 audio with power supply unit art. 1210/1210A Yes
Simplebus 1 audio Yes
ViP Yes
ELECTRICAL SPECIFICATIONS
Type of power supply
Power supply via door entry monitor BUS,
External power supply
Power supply voltage 12-33 VDC, 12 VAC
Maximum absorption (W) 3.3
Absorption with 1 bistable relay activated (mA) 75
Absorption with 2 bistable relays activated (mA) 100
HARDWARE CHARACTERISTICS
Call type Digital
Type of buttons Mechanical
Number of buttons (no.) 12
Backlighting colour White, O
Terminals
RK CK GND NO1 NC1 COM1 NO2 COM2 V- V+ D1 D0 IN GND
Number of inputs (no.) 2
Number of outputs (no.) 2
ENVIRONMENTAL AND CONFORMITY SPECIFICATIONS
Operating temperature (°C) -25 to 55
Operating humidity (max RH - %) 25 to 95
Environmental class IV
Conformity and Certifications
RoHS II - 2011/65/EU (EN 50581:2012), EMC 2014/30/EU
(EN 61000-6-1:2007, EN 61000-6-3:2007+A1:2011)
MAIN FUNCTIONS
Lock-release Yes
Voice synthesis Ye s
System status visual indications Yes
Visual indications Yes
Acoustic indications Yes
Access control via lock-release code Yes
Number of auxiliary relays (no.) 2
Number of lock-release codes (no.) 4000
