2.1 IDENTIFICATION OF PARTS
Refer to gure 1.
U.T.T.T.O
(Universal Tractor Transmission Oil)
API GL-4 JOHN DEERE J20A
Massey - Ferguson M - 1135 FORD M2C-86 B Esso TORQUE FLUID 62
Mobil MOBILFLUID 422 FORD M2C-134 B/C Shell DONAX TD
1
Intake coupling
9
Detergent intake coupling
2
Pump head
10
Oil cap (2)
3
Pressure limiting/adjustment valve
11
Delivery valve cap
4
Oil drain cap (1)
12
Thermal cut-out valve
5
Motor ange support
13
Identication label
6
Delivery coupling
14
Pump head screws
7
Pump shaft
15
Screws for motor ange support
8
Pump crankcase
16
Crankase screw
(1) Corresponding oils:
2.2 SAFETY DEVICES
Pressure limiting/adjustment valve
This valve enables adjustment of the operating pressure, allowing the pumped uid to return to the
suction unit, thus preventing the creation of dangerous levels of pressure when delivery is stopped or
should pressure be set that is above permitted levels.
« CAUTION
• The pressure limiting/adjustment valve has been correctly set by the Manufacturer or by the
Manufacturer of the machine that incorporates the pump. Never tamper with the pressure
limiting/adjustment valve in order to avoid altering its calibration.
3. DESIGNATED USE
« CAUTION
• The pump is to be used exclusively for the pumping of:
- water under high pressure in cleaning machines (high pressure cleaners);
- water which is not for human consumption;
• The pump must not be used for pumping:
- unltered water or water containing impurities;
- detergents, paints and chemicals whether neat or diluted with water
- seawater or water with a high concentration of salt;
- all fuels and lubricants;
- inammable liquids or liquid gas;
- liquids for human consumption;
- liquids at a temperature in excess of 60°C/140°F or less than 5°C/41°F;
• The pump must not be used to wash people, animals, energized electrical appliances, delicate
objects, the pump itself or the machine that it is part of.
(1) Optional for versions with horizontal axis only
(2) Only for versions with horizontal axis only
