Comeup DS-9.5 - Page 14

14
DS-9.5i
No. Description Q’ty No. Description Q’ty No. Description
Q’ty
1 Motor 1 22 Spiral spring 1 -2 Solenoid lower plate
1
2 Motor support rack 1 23 Brake cover 1 -4 Rubber cover
1
3 Gearbox support rack 1 24 Bearing 1 -5 Round cross bolt
2
4 Drum bushing 2 25 Bearing 1 -6 Remote socket plate
1
5 Drum 1 26 Spring washer 1 -7 Solenoid pack
1
6 Gear box 1 27 Hex. bolt 6 -8 Remote socket assembly
1
7 Connecting socket 1 28 Hex. bolt 4 -9 LED
1
8 1
st
shaft 1 29 Hex. lockbolt 1 -10 Hex. bolt
7
9 1
st
pinion 1 30 Hex. bolt 2 -11 Spring washer
10
10 1
st
stage carrier 1 31 Retaining ring 2 -12 Cross bolt
6
11 1
st
& 2
nd
ring gear 1 32 Anti-leakage seal 1 -13 Plain washer
6
12 2
nd
stage carrier 1 33 Spring pin 1 -14 Boot
3
13 3
rd
stage carrier 1 34 Spring pin 1 -15 Clamp
4
14 3
rd
ring gear 1 35 Foot print 1 43 Hex. bolt
4
15 Free-spool barrel 1 36 Wire rope w/hook 1 44 Spring washer
4
16 Free-spool lever 1 37 Roller fairlead 1 45 Tie bar
2
17 Pressed spring 1 38 Mounting hardware 1 46 Grounding lead
1
18 Free-spool T-handle 1 39 Remote control
1
47 Motor side cover
1
19 Brake free-spool base 1 40 Handsaver strap 1 48 Hex. bolt
4
20 Brake cam A 1 42 Integrated solenoid pack 1 49 Fastener
1
21 Cone brake disc 1 -1 Solenoid upper box
1
