4
II. Performance Data
Specifications
Model DS-9.5 DS-9.5i
Line Pull (first layer) 4,309 kg / 9,500 lb
Line Speed (first layer, no load) 19 mpm / 62.3 fpm
12V 380 A
Amp. Draw
24V 250 A
Type Series wound
12V 3,728 w / 5 hp
Motor
Output
24V 2,240 w / 3 hp
Type 3 stage planetary
Gear Train
Ratio 159 : 1
Free-spool Rotating ring gear clutch
Brake
Automatic full load cone brake
Control Detachable solenoid pack Integrated solenoid pack
Type A7 x 19 aircraft galvanized
Length 30 m / 100 ft
Wire Rope
Size 8 mm / 5 / 16 in
Performance
Model DS-9.5 DS-9.5i
Line pull (kg / lb) 4,309 / 9,500
Line speed (mpm / fpm)
2.12 / 7
1
st
layer
Rope cap (m / ft) 6.1 / 20
Line pull (kg / lb) 3,521 / 7,750
Line speed (mpm / fpm)
2.6 / 8.5
2
nd
layer
Rope cap (m / ft) 13.5 / 44.3
Line pull (kg / lb) 2,977 / 6,550
Line speed (mpm / fpm)
3.07 / 10.1
3
rd
layer
Rope cap (m / ft) 22.3 / 73.2
Line pull (kg / lb) 2,578 / 5,700
Line speed (mpm / fpm)
3.55 / 11.7
4
th
layer
Rope cap (m / ft) 32.4 / 106.3
Line speed and Amp. Draw
At the first layer of wire rope on the drum.
Model DS-9.5 / DS-9.5i
Line Pull Line Speed Amp.
Kg lb mpm fpm 12V 24V
0 0
19
62 60 35
909 2,004
4.7
15.4 115 70
1,818
4,008
3.5
11.5 210 110
2,727
6,012
2.8
9.2 245 145
3,636
8,016
2.3
7.6 280 190
4,309
9,500
2.1
6.8 380 250
