13
Ver:26
DV-6000/9000
No. Description Q’ty No. Description Q’ty No. Description
Q’ty
Motor 12V 23 Brake disc 1 Solenoid pack 12V
1
Motor 24V
1
24 Spiral spring 1
46
Solenoid pack 24V
1
2 Motor support rack 1 25 Brake cover 1 -1 Solenoid upper plate
1
3 Gearbox support rack 1 26 Bearing 1 -2 Solenoid lower plate
1
4 Drum bushing 2 27 Bearing 1 -3 Remote switch socket
1
5 Drum 1 28 Spring washer 1 -4 Socket gland
1
6 Gear box 1 29 Hex. bolt 6 -5 Screw
2
7 Motor coupling 1 30 Hex. bolt 3 -6 Nut
2
8 1
st
shaft 1 31 Hex. bolt 1 Solenoid 12V
9 1
st
pinion 1 32 Hex. bolt 1
-7
Solenoid 24V
1
10 1
st
stage carrier 1 33 Hex. bolt 1 -8 Hex bolt
5
11 1
st
& 2
nd
ring gear 1 35 Retaining ring 2 -9 Toothed washer
5
12 2
nd
stage carrier 1 36 Retaining ring 2 -10 Hex bolt
2
13 3
rd
stage carrier 1 37 Gasket 2 -11 Nut
4
14 3
rd
ring gear 1 38 Spring pin 1 -12 Spring
2
15 3
rd
bushing 1 39 Foot print 1 -13 Lead gland
3
16 Free-spool barrel 1 40 Wire rope 1 -14 Socket plate
1
17 Free-spool lever 1 41 Roller fairlead 1 47 Motor lead
1
18 Spring 1 42 Mounting hardware 1 48 Tie bar
2
19 Free-spool T-handle 1 43 Remote control
1
49 Hex bolt
4
20 Brake free-spool base 1 44 Handsaver strap
1
50 Spring washer
4
21 Brake cam 1 45 Snatch block
1
51 Free-spool ass’y
1
