Comeup DV-6000 - Page 14

14
Ver:25
DV-6000i/9000i
No. Description
Q’ty
No. Description
Q’ty
No. Description
Q’ty
Motor 12V
23 Brake disc 1
Solenoid pack 12V
1
Motor 24V
1
24 Spiral spring 1
46
Solenoid pack 24V
1
2 Motor support rack 1 25 Brake cover 1 -1 Solenoid left cover
1
3 Gearbox support rack 1 26 Bearing 1 -2 Solenoid right cover
1
4 Drum bushing 2 27 Bearing 1 -3 Upper box
1
5 Drum 1 28 Spring washer 1 -4 Rubber gland
1
6 Gear box 1 29 Hex. bolt 6 -5 Hex bolt
6
7 Motor coupling 1 30 Hex. bolt 3 Solenoid 12V
8 1
st
shaft 1 31 Hex. bolt 1
-6
Solenoid 24V
1
9 1
st
pinion 1 32 Hex. bolt 1 -7 Remote switch socket
1
10 1
st
stage carrier 1 33 Hex. bolt 1 -8 Bolt
2
11 1
st
& 2
nd
ring gear 1 35 Retaining ring 2 -9 Nut
2
12 2
nd
stage carrier 1 36 Retaining ring 2 -10 Socket gland
1
13 3
rd
stage carrier 1 37 Gasket 2 -11 Lead gland
3
14 3
rd
ring gear 1 38 Spring pin 1 -12 Tie bar screw
2
15 3
rd
bushing 1 39 Foot print 1 -13 Socket plate
1
16 Free-spool barrel 1 40 Wire rope 1 47 Hex bolt
4
17 Free-spool lever 1 41 Roller fairlead 1 48 Spring washer
4
18 Spring 1 42 Mounting hardware 1 49 Motor lead
1
19 Free-spool T-handle 1 43 Remote control
1
50 Free-spool ass’y
1
20 Brake free-spool base 1 44 Handsaver strap
1
21 Brake cam 1 45 Snatch block
1
