Comeup DV-6000 - Page 15

13
Ver:8
DV-12000/15000
No. Description
Q’ty
No. Description
Q’ty
No. Description
Q’ty
Motor 12V 27 Brake free-spool base 1 53 Solenoid pack 24V
1
1
Motor 24V
1
28 Brake cover 1 -1 Solenoid upper plate
1
2 Motor support rack 1 29 Tie bar
3
-2 solenoid lower plate
1
3 Gearbox support rack 1 31 Retaining ring 1 -3 Remote switch socket
1
4 Drum bushing 2 32 Handsaver strap 1 -4 Socket gland
1
5 Drum 1 33 Wire rope 1 -5 Screw
2
6 Motor coupling 1 34 Bearing 1 -6 Nut
2
7 1
st
shaft 1 35 Gasket A 2 Solenoid 12V
8 1
st
pinion 1 36 Gasket B 1
-7
Solenoid 24V
1
9 1
st
stage carrier 1 37 Retaining ring 2
-8
Hex bolt
5
10 2
nd
stage carrier 1 38 Hex. bolt 6 -9 Toothed washer
5
11 3
rd
stage carrier 1 39 Hex. bolt 10 -10 Hex bolt
2
12 1
st
& 2
nd
ring gear 1 40 Hex. bolt 9 -11 Nut
4
13 3
rd
ring gear 1 41 Hex. bolt 1 -12 Spring
2
14 Gear box 1 42 Hex. bolt 1 -13 Lead gland
3
15 Plain washer 1 43 Hex. bolt 1 -14 Socket plate
1
16 Free-spool lever 1 45 Hex. bolt 10 54 Foot print 1
18 Spring 1 46 Spring washer 10 55 Hook
1
19 Free-spool barrel 1 47 Spring washer 6 56 Motor lead
1
20 Spring pin 1 48 Spring washer 10 57 Bearing
1
21 Free-spool T-handle 1 49 Spring washer 9 58 Packing
1
22 Spiral spring 1 50 Mounting hardware
1
59 O-ring
1
24 Brake cam 1 51 Roller fairlead
1
60 Free-spool ass’y
1
25 Brake disc 1 52 Remote control
1
26 Brake base 1 53 Solenoid pack 12V
1
