Tensionadjustment
ofthedoorspring
【】Figure5
Tensionadjustmentofthedoorspring
●
Connectionofdrainhoses
●
Thedoorspringsaresetatthefactorytothepropertensionfortheouterdoor.
Ifaestheticwoodenpanelareinstalled,youwillhavetoadjustthedoorspringtension.
Rotatetheadjustingscrewtodrivetheadjustortostrainorrelaxthesteelcable
(seefigure5).
Doorspringtensioniscorrectwhen
thedoorremainshorizontalinthe
fullyopenedpositionyetrises
toaclosewiththeslightliftofa
finger.
，
Insertthedrainhoseintoadrainpipewithaminimumdiameterof40mm,orletitrunintothesink,makingsure
toavoidbendingorcrimpingit.Theheightofthedrainpipemustbelessthan1000mm.
A
Counter
Front
Drainpipe
NOTE
Thetopofthehose
mustbelessthan
1000mm.
φ 40mm
B
