07
INSTALLATION
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven
for any damage such as dents or broken door. Do not install if
oven is damaged.
Cabinet:
Remove any protective film found on the microwave oven cabinet
surface. Do not remove Waveguide cover that is attached to the
oven cavity to protect the magnetron.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a
heat
source, the oven could be
damaged and the warranty would
be void.
(1) Leave a minimum clearance of 12
inches (30cm) above the oven.
(2) Do not remove the legs from the
bottom of the oven.
3.0 inch(7.5cm)
>36 inch(91.4cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
1. Select a level surface that provide
enough open space for the intake
and/or outlet vents.
The accessible surface
may be hot during
operation.
A minimum clearance of 3.0 inches
(7.5cm) is required between the
oven and any adjacent walls. One
side must be open.
The minimum installation height
is 36 inches(91.4cm).
(3) Blocking the intake and/or outlet
openings can damage the oven.
(4) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven
may cause interference to your
radio or TV reception.
2. Plug your oven into a standard
household outlet. Be sure the
voltage and the frequency is the
same as the voltage the frequency
on the rating label.
To Next Page
