1.
2.
The entire light module must be replaced.
Before changing the light module(s), unplug the appliance or switch off the circuit breaker
in the fuse box.
Remove the grease filter and carefully remove the 4 screws from each side on the opening
(a Phillips head screwdriver will be needed to remove the screws).
Lower the control panel at the front by carefully pulling it downwards. You can now
access the light module and terminals.Replace the lamp.
LIGHTING
LIGHT REPLACEMENT
Replacing the light modules
2 3 4
5 6 7 8
9
11
DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old
household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old
appliances must be collected separately in order to optimize the recovery and recycling of the materials they
contain, and reduce the impact on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of
the appliance, it must be separately collected.
Consumers should contact their local authority or retailer for information concerning the correct disposal of
their old appliance.
Max Power Voltage Picture
1.5W
DC 12 V
Round/ Diameter:
2-3/4"
17473000000136
Service Number
