Comfee MFE510 User Manual

1.Check if the legs are closely attached to the cabinet. If not, please turn them to
their original positions tighten the nuts.
2.Loosen the lock nut turn the feet until it closely contacts with the floor.
3.Adjust the legs and lock them with a spanner, make sure the machine is steady.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Connect Water Supply Hose
Connect the inlet pipe as indicated, There are two ways to connect the inlet pipe.
1.Connection between ordinary tap and inlet hose.
• To prevent leakage or water damage, follow the instructions in this chapter
Do not kink, crush, modify or sever .
!
• water inlet hose
• For the model equips hot valve,connect it to hot water tap with hot water supply
hose. Energy consumption will decrease automatically for some program.
2
3
4
1
Raise
Lower
Lock nut
foot
Warning!
！
Warning!
！
9
9
INSTALLATION
Loosen clamp nut and
four bolts
Tighten clamp nut Press slide bushing,
insert inlet hose into
connecting base
slide bushing
2
3
41
Connection finished
clamp nut
Tap with threads and inlet hose
Special tap for washing machine
2.Connection between screw tap and inlet hose.
slide bushing

Comfee MFE510 Specifications

General

Door hinge	Left
Drum volume	38 L
Control type	Buttons, Rotary
Loading type	Front-load
Product color	White
Viewing window	Yes
Built-in display	No
Appliance placement	Freestanding
Drum capacity	5 kg
Cycle time (max)	232 min
Residual moisture	61 %
Spin-drying class	C
Maximum spin speed	1000 RPM
Minimum spin speed	500 RPM
Noise level (spin)	74 dB
Noise level (wash)	59 dB
Number of washing programs	23
Child lock	-
Washing class	A
Annual water consumption washing	8250 L
Annual energy consumption washing	169 kWh
Current	10 A
Connected load	1950 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	1 W
Water consumption per cycle	46 L
Energy consumption washing per cycle	0.81 kWh
Package depth	555 mm
Package width	650 mm
Package height	885 mm
Package weight	57000 g

Weight and Dimensions

Depth	470 mm
Width	595 mm
Height	850 mm
Weight	54000 g
Door diameter	300 mm
