Installation
Before installing the machine, the location characterized
follows shall be selected:
1.Rigid, dry, and level surface
2.Avoid direct sunlight
3.Sufficient ventilation
4.Room temperature is above 0℃
5.Keep far away from the heat resources such as coal or gas.
as
Unpacking the washing machine
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
Make sure the small triangle
foam is removed with the bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom manually.
Please take the following steps to remove the bolts:
1.Loosen 4 bolts with spanner and then remove them.
2.Stop the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Remove transport bolts
•
•
Stability is important to prevent the product from
wandering!
Make sure that the product should not stand on
the power cord.
Warning!
！
•
•
Packaging material (e.g. Films, Styrofoam) can be
dangerous for children.
There is a risk of suffocation ! Keep all packaging
well away from children.
Warning!
！
•
• product
you
You must remove the transport bolts from the backside before using the product.
You’ll need the transport bolts again if you move the , so make sure
keep them in a safe place.
Warning!
！
8
INSTALLATION
w
w
W> 20mm
Installation area

Comfee MFE510 Specifications

General

Door hinge	Left
Drum volume	38 L
Control type	Buttons, Rotary
Loading type	Front-load
Product color	White
Viewing window	Yes
Built-in display	No
Appliance placement	Freestanding
Drum capacity	5 kg
Cycle time (max)	232 min
Residual moisture	61 %
Spin-drying class	C
Maximum spin speed	1000 RPM
Minimum spin speed	500 RPM
Noise level (spin)	74 dB
Noise level (wash)	59 dB
Number of washing programs	23
Child lock	-
Washing class	A
Annual water consumption washing	8250 L
Annual energy consumption washing	169 kWh
Current	10 A
Connected load	1950 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	1 W
Water consumption per cycle	46 L
Energy consumption washing per cycle	0.81 kWh
Package depth	555 mm
Package width	650 mm
Package height	885 mm
Package weight	57000 g

Weight and Dimensions

Depth	470 mm
Width	595 mm
Height	850 mm
Weight	54000 g
Door diameter	300 mm
