Confirm your window type (window type and opening size
of dierent types)
Sliding Window Installation Hung Window Installation
To ensure proper function, DO NOT overextend
or bend the hose. Make sure that there is no
obstacle around the air outlet of the exhaust hose
(in the range of 500mm) in order to the exhaust
system works properly. All the illustrations in this
manual are for explanation purpose only. Your air
conditioner may be slightly dierent. The actual
shape shall prevail.
NOTE:
INCORRECT
CORRECT
For optimal performance in operation
