NOTE: Please install the exhaust hose assembly according to the fittings in your kit.
Unit adaptor
Window slider
adaptor
Exhaust hose
Exhaust hose
assembly
Model A Model B
Window slider
adaptor
Exhaust hose
assembly
Exhaust hose
Air exhaust
passage
Unit adaptor
Exhaust hose
Extended Exhaust
hose
Exhaust hose assembly
Model DModel C
Exhaust hose
assembly
Exhaust hose
Unit adaptor
Air exhaust
passage
Press the exhaust hose(or extended exhaust hose) into the window slider adaptor
and unit adaptor, clamp automatically by elastic buckles of the adaptors.
The Exhaust Hose assembly installation (window type)
Installation guide
