Connect the adaptor to the unit and the window
MODEL A MODEL B
1+2：
Bolt
1+2+3：
Bolt
Bolt
1+2+3+4：
Bolt
BoltBolt
1+4：
Bolt
Window
Sliders
After assembly
Before assembly
Window
Sliders
After assembly
Before assembly
MODEL C
Bolt
Bolt
1+2：
1+2+3：
Bolt
2
NOTE: Please base your window slider installation on the accessories in your kit and the width of
your window.
Preparing the Adjustable Window Slider
Choose the window sliders according the size of your window. Sometimes, it needs
to be cut short to meet the window size, please take extra care to cut it properly.
Use bolts to fasten the window sliders once they
are adjusted to the Proper length.
Window slider A Window slider B
Bolt
Window slider A
Window slider B
Window slider C
Bolt
Inside
Outside
or
