3. Components of your blood pressure monitor
There are six grids in the display of device. Please refer to the picture-01-01.
Different grids represent different interval scales of WHO.
Picture-02
Picture-03
3.3 Features of Model B15S
3.2 The symbols on the LCD display
Cuff Connector Port USB Port
15
14
LCD Display
SET
Memory
Start/Stop
2. Double users: 2 x 120 sets memory
4. Irregular heartbeat checking
6. Low battery display
8. Auto power-off
10.Volume adjustment
1.Talking function
3.Cuff self-checking function
5. Average value function
7. WHO function
9. External power adapter support
11. Date/time display
1.Systolic blood pressure 2.Diastolic blood pressure
3.Heartbeat symbol (Flashes during measurement)
4.Pulse display 5.WHO Function symbol
6.Average value symbol 7.Date/Time display
8.Battery low symbol 9.Mute symbol
10.Irregular heartbeat symbol 11.Movement error symbol
12.User B 13.User A
14.Cuff self-checking function 15. Memory symbo
