This document provides information for installation of the touchscreen control only.
Installation instructions for the furnace or air handler and outdoor AC condensing unit
or heat pump are provided with each of these devices.
This thermostat is designed exclusively for Amana/Goodman brand ComfortNET
TM
System equipment ONLY. This thermostat can ONLY be used with compatible Amana
®
brand or Goodman brand Air handlers or Furnaces, and outdoor AC or Heat Pump
condensing units.
Co n t r o l Ki t S Co n t e n t S
This communicating control kit contains the following components:
(1) Communicating touchscreen control with sub base
(1) 230 VAC to 24 VAC, 40 VA transformer (B1141643)
(2) Tyco 284041-4, 4-position plug color-coded connectors
(1) Blue wire jumper (14”)
(1) Red wire jumper (22”)
(1) Black wire jumper (22”)
(1) Red wire jumper (14”)
(2) #10 Sheet metal screws
(1) Instruction manual (IO-350)
(1) Homeowner User Guide (HI-123)
(1) Quick Start Guide (IO-722)
Va l i D Sy S t e m Co n f i g u r a t i o n S
This control may only be used with certain system congurations. Valid system
congurations for which this control can be used are:
A communicating air handler matched with a communicating outdoor
AC condensing unit
A communicating air handler matched with a communicating outdoor
heat pump unit
In s t a l l a t I o n
NOTES
WARNING
!
