STEP 4: CONNECT ALL CABLES TO THE ADAPTOR
3
6
5
6
8
Connect the power after the
wiring is completed.
Fix the cables to the tabletop with cable
management (7) to keep desk clean.
Insert the adaptor (6) to the bracket of the tabletop.
Connect the switch cable to
the DC port.
Connect the motor cable to
the M1 port.
Ripped
Fixed
Organize
the lines
