Contents
Assembly:Part 1
Y-axis base
Spindle motor
Wrenches
Milling tool kit
M5X10 Screw *8 T-nuts *8 Butterfly nuts *4 M5X40 Screw *8
M4X25 Screw &
Square Nut*1
Brushe M5X12 Screw *10 Hexagonal wrench Wire Buckle
Clamps*4 SD Card USB cable
Tool setting gauge
block
Spindle Tool holders offline control handle
XZ-axis gantry Protective baffle Plug 24V/5A Adapter
offline control
handle cable
+
Remove the two protective baffles (a)
and install the M5*10 (c) screws and M5 T-nuts (d)
Install the protective baffle on both sides of the
Y-axis base (b)
(d)
(a)
(c)
a:Protective baffle(x2)
b:Y-axis base(x1)
c:M5X10 Screw(x8)
d:M5 T-nuts(x8)
