Assembly:Part 3
Ready:
Assembly:Part 2
e:back side panel(x1) g:M5X12 Screw(x6)
h:XZ-axis gantry(x1)
f:M5X12 Screw(x2)
(h)
(g)
(e)
Use two M5*12 screws (f) to secure the back side panel (e)
to the rear of the Y-axis base
Using six M5*12 screws (g) ,
secure the XZ-axis gantry (h)
to the side of the Y-axis base.
(f)
