Offline Controller
Notice: If you want to run the CNC machine with an offline controller, you must first disconnect the
USB cable from the controller board.
1. Connect the memory card to the computer through a card reader, copy the G-code into the memory card, and then insert the memory card into the offline control handle.
2. Connect the offline controller to the control motherboard.
3. Press the [X+/X-/Y+/Y-/Z+/Z-] key to move the spindle to the machine origin, select the engraving file, click the [OK] key to start engraving.
4. Interface introduction
1514
OK
Confirmation
BACK Return to previous page
RESET Reset system
X-/X+/Y-/Y+/Z-/Z+ Control X/Y/Z axise move
Move
Confirmation
File Return to previous page
SSet Reset system
Press key [X-] or [X+] to select
Laser/SPN:100%
Power to spindle
(press [Z+]=add,Press [Z-]=reduce)
A. Off-line controller button B. Menu PagAe
Press key [OK] to Enter
Press key [RESET] to reset system
To Next Page
