Receiver
1. 3.5mm Monitoring Port: Plug in 3.5mm TRS/TRRS headphones for monitoring
2. 3.5mm Output Port: To identify TRS/TRRS plug automatically and output analog audio through the 3.5mm TRS-TRS/TRRS-TRRS audio cable
3. USB-C Charging/Output Port: To charge or output digital audio with the 2 in 1 charging&output cable
4. Reset Hole: If there is an abnormal phenomenon such as the device is crash or unable to turn on it, then insert the reset pin into the reset hole to reset it
5. Power/Mute Button: Long press to power on/o; Short press to turn on/o the mute function
6. Gain Control/Screen Flip/Pairing Buttons: Short press to adjust the gain; Long press to flip the screen; Long press the two buttons in sync to enter pairing
state
7. Belt Clip
① ②
③ ⑦
④
⑤
⑥
5
