5. Specifications
Model
Specifications
MTX0804RA, MTX0808RA MTX1608RA, MTX1616RA
Video
Bandwidth
400MHz (-3dB), fully loaded
0 -10MHz @ ± 0.1dB
0 -100MHz @ ± 0.6dB
Cross talk sum 0.03 Deg.
Differential phase error 0.1°, 0.1%
Differential gain error 0.1%, 3.58-4.43MHz
Switching speed 200 ns (Max)
Signal type
RGBHV，RGBS， RGsB， RsGsBs， HDTV， Component Video，S-Video， Composite Video
Input video
Connector BNC female
Signal strength
1V p-p Y Component Video、S-Video，Composite Video； 0.7V p-p RGB；0.3V p-p R-Y & B-Y
Component Video、 S-Video
Maximum/Minimum
level
Analog signals: 0.5V ~ 2.0V p-p
Impedance
75 Ω
Output video
Connector BNC female
Maximum/Minimum
level
2.0V p-p
Impedance
75 Ω
Max compensation in
Dc offset
±5mV
Gain 1.03 dB
Sync signal
Input/output signals
RGBHV, RGBS, RGsB, RsGsBs,
Input level
0.5V- 5.0V p-p,: 4.0V p-p normal
Output level
AGC-TTL: 5Vp-p, unterminated
Input impedance
510 Ω
Output impedance
75 Ω
Polarity
Straight or subtractive according to input
Audio signal
I/O connector
3.8mm with screw , 5 pole
Gain
0dB
Frequency respond
20 Hz ~ 20 kHz,
General harmonic
distortion + noise
0.03% @ 1 kHz （under rating voltage）
S/N
>90dB
Segregation rate
>80dB @ 1 kHz
CMRR
>75dB @: 20 Hz ~ 20 kHz
Signal
Stereo ，balanced /unbalanced
Impedance
Input：>10 kΩ（balanced /unbalanced）
Output：50 Ω （unbalanced）, 100 Ω（balanced）
Maximum input level
+19.5dBu, （balanced /unbalanced）
Gain error
±0.1dB
