Technical Specications – Standard DC Models (408D)
Dimensions (with strobe and ½" mounting spacers) – May vary by model:
Height(Depth) Length Width
Retracted
12" 47" 23"
Extended
88" 52" 23"
Recessed installation
14" 58" 30" Minimum
Weight: 165 pounds
Wiring:
Main Power VDC 2/2 SO cord 50' provided
Control wiring 22/20 PVC Jacketed 50' provided
Relay protection:
Lights Cole-Hersey 3055 80 amps
Other electrical Cole-Hersey 3055 40 amp
Current Draw / Power Requirements:
Average Generator Requirement
75 Watt LED
12 VDC/40 amps 1 kW minimum
Lift actuators and rotation motor will cause higher current draw during use.
Motor Duty Cycle:
(All motors thermally protected, specications are to thermal relay trip):
Lower stage 1:3 (90 seconds maximum per 5 minute)
Upper stage 1:3 (90 seconds maximum per 5 minute)
Rotation 5-6 Revolutions
Motor Speed:
Lower stage 1.0 inches per minute 12 seconds to full extension
Upper stage 0.5 inches per minute 12 seconds to full extension
Rotation 2.75 RPM at lamp tree
Operation:
Angle of vehicle 15˚ maximum incline
Wind load:
Design maximum 60 mph
Maximum tested 55 mph
