(2) SCREEN MODE : to set for screen ratio
① ZOOM: Zoon in(expansion) image maintaining actual ratio(4:3) is shown. (full of the
screen)
② 4:3: Image of 4:3 ratio without expansion is shown.(This is actual ratio for camera)
③ WIDE: Full of the screen. Not actual ratio (4:3). Image is expanded according to LCD
(WIDE LCD) ratio.
※ How to adjust
① Access to SCREEN MODE with
△ /▽ button in UTILITY Menu
② Press SELECT button to enter the menu.
③ Adjust screen ratio value with◁
/▷button.
④ To complete the set, press SELECT button.
7
7
(3) EXIT : Go back to Setting menu
7-3. INFORMATION (The function to check Model name & Version)
In order to check the product information, press menu button and move to INFORMATION
menu with ◁/ ▷ button.
(1) MODEL : You can check the model name.
(2) VERSION : You can check the model version.
(3) SYSTEM : SINGLE (FINE VIEW VIDEOPHONE)
(4) TOUCH : You can check the touch-key version
(5) VIDEO : You can check the video transmission formats(NTSC / PAL)
(6) SOURCE : You
can check the position of camera(DOOR) which is shown
on the screen for now.
7-4. EXIT(Finish setting menu)
Specifications and Features
Power source
Power Consumption
Standby : 2.5W, Operating : 15W
Wiring 4 wires with door camera (Polarity),
4 wires with an Interphone (Polarity)
Screen Size
Color 7" TFT LCD
Communication Simultaneous communication
From a door camera : Electric chime
From an interphone : Beep sound
Time to display the screen 60 ± 10sec
Distance from camera 28m(Ф0.5) / 50m(Ф0.65) / 70m(Ф0.8)
Operating Temperature 0 ~ +40℃ (32°F ~ 104°F)
Call Sound
Reference : Design and functions of the product are a subject of constant
development as a pursuit of quality improvement
8.
100-240V~, 50/60Hz(FREE VOLTAGE)
To Next Page
