Commax DP-4VHP User Manual

1
Table of Contents
Warnings and caution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1. General Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4. Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5. Specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Commax DP-4VHP Specifications

General

Power Voltage	220V~, 50/60Hz
Power Consumption	MAX : 4 W (220V/60Hz)
Transmission	To Master unit : 4wires
Communication Method	Handset
Sound	From Outdoor unit : Electronic Chime
Time	60 ± 20sec
Distance	28m(Ø0.5) / 50m(Ø0.65) / 70m(Ø0.8)
Operating Temperature	0 ~ +50°C

Weight and Dimensions

Weight	0.55 kg
Dimension	107(W)X195(H)X52(D) mm
