Commax DRC-4CPN2 User Manual

2
Your unit is designed so it can be flush mounted on the or used. When flush mounted on the wall, the stand permils you to the
unit for an gular of unit view. The model number is located on the bottom and record the serial number in the space provided
below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product.
Model No. Serial No.
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
This symbol is intended to alert the use to the presence of uninsulated
“
“
dangerous Voltage
”
”
within the product’s enclose that
may be of sufficient magnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the use to the presence of important operating and maintemance(servicing) instructions in the
literature accompanying the appliance
CAUTION: To reduce the risk of electrix shick, do not remove cover(or back) no user-serviceable
part sinside refer servicing to quaured service personnel
caution
Rosk of electric shock
do not open
1. Introduction
www.safemag.ru
www.safemag.ru

Commax DRC-4CPN2 Specifications

General

Image Sensor	CMOS 1/3"
Sensor Resolution	0.41 megapixel
Camera angle	Horizontal angle 68° Vertical angle 55°
Low illumination	0.1 LUX (Up to 300mm in front of the camera)
Power source	12V (supplied from the Monitor)
Wiring(household)	Polar 4 wires
Call mode	Duplex
Lamp	Built-in white LED (automatically turns on in night)
Format	NTSC or PAL STANDARD
Horizontal / vertical Frequency	15.734㎑/ 60㎐or 15.625㎑/ 50㎐
Workable temperature	-10℃(tested up to -40℃) +50℃

Weight and Dimensions

Dimension(mm)	50(W) x 118 (H) x 25.5(D)
Weight(g)	250g (B/K included)
