Commax DRC-4CPN2 User Manual

6
1. Align holes on the wall where the unit is to be installed with mounting brackets hole and
secure.
FIG-1 : Install the camera at a 30˚angle to the left
(install the bracket in reverse to angle 30˚to the right)
FIG-2 : Install the camera at a perpendicular angle to the front
2. Wire the household monitor cables as shown below with matched polarity as picture
below[FIG-3]
(#1:RED/VOICE, #2:BLUE/GND, #3:YELLOW/DC12V, #4:BLACK/VIDEO)
3. Wire the door release cable as shown in the diagram.[FIG-3]
4. Tighten using bolts and a wrench, then cover using the AL. screw covers.
4. Wiring & Installation
www.safemag.ru
www.safemag.ru

Commax DRC-4CPN2 Specifications

General

Image Sensor	CMOS 1/3"
Sensor Resolution	0.41 megapixel
Camera angle	Horizontal angle 68° Vertical angle 55°
Low illumination	0.1 LUX (Up to 300mm in front of the camera)
Power source	12V (supplied from the Monitor)
Wiring(household)	Polar 4 wires
Call mode	Duplex
Lamp	Built-in white LED (automatically turns on in night)
Format	NTSC or PAL STANDARD
Horizontal / vertical Frequency	15.734㎑/ 60㎐or 15.625㎑/ 50㎐
Workable temperature	-10℃(tested up to -40℃) +50℃

Weight and Dimensions

Dimension(mm)	50(W) x 118 (H) x 25.5(D)
Weight(g)	250g (B/K included)
