DRC-4G
DC 12V (Supplied to monitor)
4 wires (polarity) to a monitor
2 wires (non-polarity) to a electric door lock
NTSC or PAL STANDARD.
CMOS IMAGE SENSOR
Full duplex
0.1 Lux (within 300mm)
Embedded white LED (night working)
Horizontal 75°, Vertical 55°
Upward 13
-10℃(tested up to -40°C)~ +40℃
300g
101(W) x 142(H) x 32(D)
Diameter(pie) Ø
0.5
Ø
0.6
Ø
0.8
Ø
1
Distance(meter)
28m 50m 70m 115m
Model No.
Rated Voltage
Wiring
Video Transmission Standard
Sensor Type
Transmission
Minimum Illumination
LED
Effective Viewing Angle
Angle Adjustment
Operating Temperature
Weight (g)
Dimension (mm)
Installation between a door
camera and a monitor(TIV Cable)
Wiring
