Commercial Electric AK366-TM User Manual

18 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

THANK YOU

USE AND CARE GUIDE

6 ft. / 8 ft. / 10 ft. HIGH VELOCITY

INDOOR/COVERED OUTDOOR CEILING FAN

We appreciate the trust and condence you have placed in Commercial Electric through the purchase of this ceiling fan. We strive to

continually create quality products designed to enhance your home. Visit us online to see our full line of products available for

your home improvement needs. Thank you for choosing Commercial Electric!

1-833-HDFANS-1 / (1-833-433-2671)

HOMEDEPOT.COM

Questions, problems, missing parts? Before returning to the store,

8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday

call Commercial Electric Customer Service

Visual instruction of how to install this fan:

Visit www.homedepot.com and enter either the Item or Model number to nd

this fan and click the link of visual instruction in the product overview section.

Item #1009 847 953

1009 847 948

Model #AK366-MBK

AK366-TM

10 ft.

6 ft. 8 ft.

Item #1009 847 949

1009 847 952

Model #AK366B-MBK

AK366B-TM

Item #1009 847 950

1009 847 951

Model #AK366A-MBK

AK366A-TM

Table of Contents

Questions and Answers:

W
William SmithAug 10, 2025
How to fix a noisy Commercial Electric AK366-TM Fan?
- D
  Deborah HarrisonAug 10, 2025
  To reduce fan noise, ensure all motor housing screws are snug and that the screws attaching the fan blades to the motor hub are tight. Also, check that wire nut connections are not rattling against each other or the switch housing's interior wall. Allow the fan a 24-hour 'breaking-in' period, as most noises disappear during this time. If your fan has a ceiling light kit, make sure the glassware is secured tightly and that there is a short distance from the ceiling to the canopy, without it touching the ceiling. Finally, ensure your ceiling box is secure, using rubber isolator pads between the mounting bracket and outlet box.
N
Natasha StephensonAug 17, 2025
What to do if my Commercial Electric Fan won't start?
- F
  Frank PetersonAug 17, 2025
  If your fan won't start, begin by checking the main and branch circuit fuses or breakers. Then, inspect the line wire connections to the fan and the switch wire connections in the switch housing. Ensure that the frequency switches on both the remote control and receiver are set to the same frequency. Try turning the AC power off, waiting 10 seconds, and then turning it back on. Finally, reset the transmitter by performing the “LEARNING PROCESS”.
E
Elizabeth JohnsonAug 26, 2025
Why is my Commercial Electric AK366-TM wobbling?
- K
  Kimberly PetersAug 26, 2025
  Fan wobble is often due to loose parts. First, make sure all blades and blade bracket screws are secure. After proper installation, let the ceiling fan run for 10 minutes to self-adjust. If wobbling continues, check the blade level: measure from each blade's center to a point on the ceiling, deviations should be within 1/8 inch. If deviations exceed 1/8 inch, contact Customer Service at 1-833-HDFANS-1 / (1-833-433-2671) to order complimentary replacements of your brackets. If deviations are less than 1/8 inch, call Customer Service to order a complimentary blade balancing kit.
F
Felicia MorrisSep 2, 2025
Why does my Commercial Electric AK366-TM move backwards and forwards when turned on?
- R
  Ronald MillerSep 2, 2025
  This start-up movement is normal for DC motor fans. The partial movement is the DC motor aligning the internal magnetic poles for proper operation. This design saves electricity and allows the fan to operate much quieter than standard AC motor fans.

Commercial Electric AK366-TM Specifications

General

Brand	Commercial Electric
Model	AK366-TM
Type	Ceiling Fan
Reversible Motor	Yes
Mounting Type	Downrod Mount
Warranty	Limited Lifetime
Motor Type	AC Motor
Motor Speed	3-speed

Summary

Safety Information

Installation

MOUNTING OPTIONS

Assembly

Assembling the fan

Attaching the mounting bracket to the electrical box

Steps for attaching the mounting bracket to the ceiling electrical box.

Hanging the fan on the mounting bracket

Making the electrical connections

Detailed instructions for making wire connections from the fan to the house wiring.

Installing the wall control

Steps for installing the wall control unit and plate.

Installing the canopy

Attaching the blades to the blade arms

11a Fastening the blade assemblies to the motor

Instructions for fastening blade arms to the fan motor assembly.

11b Fastening the blade assemblies to the motor

Instructions for fastening the remaining blade arms to the fan motor.

Installing the Light Kit

Attaching the LED light kit to the light kit mounting plate

Instructions for connecting and attaching the LED light kit.

Operation

WALL CONTROL OPERATING INSTRUCTIONS

Explains how to use the wall control buttons and functions.

LEARNING PROCESS

WARM/COOL WEATHER OPERATING INSTRUCTIONS

Troubleshooting

The fan will not start.

The remote control is not working.

The fan wobbles.

Steps to diagnose and fix fan wobble, including balancing.

Fan moves backwards and forwards when turned on.
