ComNav 1101 Autopilot5 - 10 GETTING STARTED
2. Using the PORT DODGE button, move the rudder until it stops
at the port Hard-over limit that was set during the Rudder Drive
Test.
3. Press the STARBOARD DODGE button and note the time it
takes for the rudder to travel all the way to the starboard Hard-
over limit. This is the Hard-over to Hard-over time.
4. Compare the results obtained with the guideline chart shown
below. If the results obtained are not within 20% of the
guidelines, your steering system should be adjusted. If you are
unsure or not able to make the necessar y adjustments, contact
your ComNav dealer or the factory for advice. Once you have
adjusted the steering system for correct Hard-over to Hard-over
timing, perform a RESET and redo your Rudder Drive Test.
Vessel Length Hard-over to Vessel Speed
(meters/feet) Hard-over time (seconds) (knots)
5.5m-10.5m (18-35) 8-12 Up to 30
10.5m-18m (35-60) 12-16 Up to 30
18m-30.5m (60-100) 14-18 Up to 30
30.5m-70m (100-200) 16-24 Up to 25
There are some exceptions to the above. Contact your ComNav
dealer or the factory for assistance on vessels with unique charac-
teristics.
