User Notes & Settings
User Settings
Once your Vector G2 has been installed and configured correctly, you can make a record of
all the settings you have chosen, in the tables below.
Port A Port B
Sentences Range Default Yours Default Yours
GPDTM 0, 0.2, 1, 5 or 10 0 0
GPGGA 0, 0.2, 1, 5 or 10 1 0
GPGLL 0, 0.2, 1, 5, 10 or 20 1 0
GPGNS 0, 0.2, 1, 5 or 10 0 0
GPGRS 0, 0.2, 1, 5 or 10 0 0
GPGSA 0 or 1 0.2 0
GPGST 0 or 1 0.2 0
GPGSV 0 or 1 0.2 0
GPHDG 0, 0.2, 1, 5, 10 or 20 1 0
GPHDM 0, 0.2, 1, 5, 10 or 20 1 10
GPHDT 0, 0.2, 1, 5, 10 or 20 1 10
GPRMC 0, 0.2, 1, 5 or 10 0.2 0
GPROT 0, 0.2, 1, 5 or 10 1 0
GPRRE 0 or 1 0 0
GPVTG 0, 0.2, 1, 5 or 10 1 1
GPZDA 0, 0.2, 1, 5 or 10 1 0
PCSI,CS0 0 or 1 0 0
PCSI,CS1 0, 0.2, 1, 5 or 10 0 0
PSAT,GBS 0, 0.2, 1, 5 or 10 0 0
PSAT,HPR 0 or 1 1 0
PSAT,INTLT 0 or 1 0 0
RD1 0 or 1 0 0
BAUD rate
4800, 9600, 19200,
38400
4800 4800
Table 16 – User Settings (Ports)
Parameter Range Default Yours
Alignment Fore-Aft or Athwartships Fore-Aft
ROLL NO, YES NO
HBIAS -180.0° to 180.0° 0.0
PBIAS -15.0° to 15.0° 0.0
G2 NONE
DIFF
NONE, WAAS, EXTERNAL
(G2B: also BEACON)
G2B BEACON
GYROAID NO, YES YES
TILTAID NO, YES YES
NMEAHE 0, 1 0
COGTAU 0.0 to 200.0 0.0
HTAU 0.0 to 3600.0 2.0
HRTAU 0.0 to 3600.0 2.0
PTAU 0.0 to 3600.0 0.5
SPDTAU 0.0 to 200.0 0.0
SMOOTH SHORT, LONG, 15 to 6000 900
Table 17 – User Settings (Alignment & Operational)
