Comnet FDX60M1A-M - FDX60-M 2 Fiber Transceiver Illustrations

INS_FDX60_REV–
04/23/10
PAGE 5
NOTE: Remove Electrical Connector for Rack Mount Units
MULTIMODE OR
SINGLE MODE
OPTICAL FIBER
BLACK
BLACK WITH WHITE
STRIPE/RED
FIGURE 8 – FDX60-M 2 FIBER TRANSCEIVER
FIGURE 7 – FDX60-M 2 FIBER TRANSCEIVER
INSTALLATION AND OPERATION MANUAL FDX60(M)(S)(-M)
REAR PANELFRONT PANEL
TECH SUPPORT: 1.888.678.9427
