2-4
Operating Controls
Operating Controls
Item No. Description
1 Speed range selector switch
2 Attachment tilt control
3 Attachment raise control
4 Engine throttle
5 Travel creep speed control
6 Fuel filler cap
7Fuel tank
8 Service panel lock
9 Hand grip rail
10 Left travel motor control
11 Right travel motor control
12 Auxiliary attachment hydraulic control
