3-11
Pre-Start Inspection and Operation
6. (Gasoline Units Only) Shut off the in-fuel valves underneath each of the fuel tanks (Item 1,
Figure 3–11) when transporting the unit to prevent possible carburetor flooding due to
vibration.
Figure 3–11 Fuel Shut Off Valves
NOTE:
• Never tow or pull the machine. Damage to the hydraulic motors could result.
• If the machine is totally in-operable, using lifting straps or cables and a machine that can
safely lift 4,000 lbs (1820 Kg), lift the machine and place on a trailer.
1
Left Side of Engine
1
RightSide of Engine
2041
2033
To Next Page
