4-13
Routine Service and Maintenance
5. Check both spark plugs (Items 1 and 2, Figure 4–17) for damage to the spark plug cables.
Figure 4–17 Check Spark Plugs and Cables
6. Check the battery (Item 1, Figure 4–18) and cable connections (Items 2 and 3, Figure 4–18)
for signs of leaking, corrosion or damage. (Some items have been removed for clarity.)
Figure 4–18 Battery and Cable Connections
1
2
2044
1
2
3
2045
