WATER SUPPLY AND DRAIN LINE
SIZING/CONNECTIONS
Tubing Size Up to
Ice Machine
Fitting
1/4" (.64 cm)
min. inside
diameter
3/4" (1.9 cm)
minimum inside
diameter
3/8" (.96 cm) ID
minimum
Ice Machine
Fitting
1/4" (.64 cm)
ID Copper
Tubing
3/4" (1.9 cm)
Hose Barb
3/8" (.96 cm)
Hose
Water
Pressure
20 psi (1.38 bar) Min
80 psi (5.5 bar) Max
----- -----
Water
Temperature
35°F (1.7°C) Min.
90°F (32.°C) Max.
-----.
-----
Ice Making
Water Inlet
Bin Drain
Drain Pump
Note: If air temperature is less than 60 F (15.5 C) water temperature must be equal or greater
than 50°F (10°C).
