The grinder should rest on a flat, hard surface in close proximity to the
coffee machine. To guarantee proper operation, the minimum work space
should measure at least 310 mm wide by 400 mm deep by 800 mm high.
Unpack the grinder carefully and place it in the assigned work space.
Before placing the bean hopper on the grinder, loosen the security screw
found on the upper collar of the grinder (4). Place the bean hopper
(2) on the upper part of the grinder so that the bean trap lever (3) is
positioned on the right side of the grinder in the CLOSED position (Fig. 1).
Once the bean hopper is placed on the grinder, rotate it clockwise until it
is firmly in place and can rotate no further. If desired, replace the hopper
security screw (4) to ensure the hopper cannot be removed manually.
Place beans in the hopper and replace hopper lid (1). Finally, the bean
trap lever (3) must be in an open position, allowing the beans to fall into
the grinding chamber.
Before plugging in the grinder, confirm that the electrical configuration
found on the description plaque on the grinder matches the power on
site. Once confirmed, plug in the grinder and press the 3 position switch
(15) to position 2. The refill button (8), main display (6), and 3 position
(15), will all illuminate once connected when the power (Fig. 1). If the
bean hopper has not been installed properly, the main display (6) will
show error message “Hopper!”
External Features
4
Installation
5
All models in the Fresh line of grinders share the following external
features, independent of burr size, voltage or model.
Fig. 1
ORIGINAL INSTRUCTIONS
12
11
10
9
8
7
6
5
3
2
1
Hopper lid
Hopper
Bean trap
lever
Hopper security
screw
Grind adjustment
knob
Main display
Configuration
buttons
Refill button
Exit chute
Upper
portafilter
holder
Dosis button
Lower
portafilter
holder
Fork
adjustment
screw
Coffee tray
3 position
switch
4
13
15
14
