Phillips PM2.5×9.0 captive screw
Color Quantity Length Thread Head diameter
Black 4 9.0 mm 2.5 mm 5.0 mm
Where used:
(1) One captive screw that secures the optical drive to the computer (screw is secured by a C-clip)
(2) Three captive screws that secure the keyboard to the computer (screws are secured by C-clips)
Phillips PM2.0×3.0 screw
126 Chapter 7 Screw listing
