Compaq 6530b - Notebook PC User Manual

Item Component Function
(4) Webcam light (select models only) On: The integrated camera is in use.
(5) HP Webcam (select models only) Records audio and video and captures still photographs.
Buttons, switches, and fingerprint reader
Item Component Function
(1) Fingerprint reader (select models only) Allows a fingerprint logon to Windows, instead of a password
logon.
(2) Power button
●
When the computer is off, press the button to turn on the
computer.
●
When the computer is on, press the button to initiate
Hibernation.
●
When the computer is in Hibernation, press the button
briefly to exit Hibernation.
●
When the computer is in the Sleep state, press the button
briefly to exit Sleep.
If the computer has stopped responding and Windows®
shutdown procedures are ineffective, press and hold the power
button for at least 5 seconds to turn off the computer.
To learn more about your power settings, select Start >
Control Panel > System and Maintenance > Power
Options.
(3) Internal display switch Turns off the display if the display is closed while the power is
on.
10 Chapter 2 External component identification

Compaq 6530b - Notebook PC Specifications

General

Processor	Intel Core 2 Duo
Graphics	Intel GMA 4500MHD
Operating System	Windows Vista Business
Battery Life	Up to 4 hours
Display	14.1-inch WXGA (1280x800)
Memory	Up to 4GB DDR2
Storage	120 GB to 250 GB 5400 rpm SATA
Battery	6-cell Lithium-Ion
Chipset	Mobile Intel GM45 Express
Optical Drive	DVD+/-RW SuperMulti with Double Layer
Networking	Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
Wireless	802.11a/b/g/n
Audio	High Definition Audio, stereo speakers
Ports	VGA, RJ-45
Slots	ExpressCard/54
Processor Speed	2.53 GHz
