Item Description Spare part
number
For use in Spain 486279-071
For use in Sweden 486279-B71
For use in Switzerland 486279-BG1
For use in Taiwan 486279-AB1
For use in Thailand 486279-281
For use in Turkey 486279-141
For use in the United Kingdom 486279-031
For use in the United States 486279-001
Memory modules (PC2-6400, 667-MHz, DDR2)
(4a) Primary memory module (located under keyboard)
(4b) Expansion memory module (located under memory/WLAN module compartment cover)
2048-MB 483194-001
1024-MB 483193-001
TouchPad assemblies (include the components listed below):
(5a) Fingerprint reader board and cable (included only in spare part kit 486277-001)
(5b) TouchPad board and cable
(5c) TouchPad board bracket
For use only with computer models equipped with a fingerprint reader (includes a fingerprint
reader board and cable)
486277-001
For use only with computer models not equipped with a fingerprint reader 486278-001
Plastics Kit (see Plastics Kit on page 29 for more Plastics Kit spare part information): 486292-001
(6a) PC Card slot bezel
(6b) Memory/WLAN module compartment cover
(6c) Hard drive bay cover
(6d) Bluetooth module compartment cover
Cable Kit (see Cable Kit on page 30 for more Cable Kit spare part information): 486281-001
(7a) Bluetooth module cable
(7b) Modem module cable (includes RJ-11 connector)
(7c) Microphone extension cable
System boards (include system board bracket, system board, and replacement thermal material):
(8a) System board bracket
(8b) System board
For use only with HP Compaq 6535b computer models equipped with both WLAN and WWAN
modules
488193-001
24 Chapter 3 Illustrated parts catalog
