Spare part
number
Description
486285-001 Base enclosure for use only with computer models not equipped with a WWAN module (does not include SIM
slot opening)
486286-001 Display enclosure
486287-001 Display hinge covers (includes left and right hinge covers)
486288-001 Fan
486289-001 Heat sink for use only with HP Compaq 6530b computer models (includes replacement thermal material)
486290-001 Display Logo Kit
486291-001 Rear cover
486292-001 Plastics Kit (see Plastics Kit on page 29 for more Plastics Kit spare part information)
486293-001 Rubber Kit (not illustrated, contains 7 computer feet)
486294-001 Screw Kit
486295-001 6-cell, 47-Wh Li-ion battery
486296-001 6-cell, 55-Wh Li-ion battery
486770-001 Display bezel for use only with computer models equipped with a webcam
486772-001 Display hinges (includes left and right hinges)
486773-001 Display inverter for use only with HP Compaq 6530b computer models
486774-001 Display Screw Kit
486775-001 Display Rubber Kit (includes display bezel screw covers)
486776-001 Display panel cable
486777-001 WLAN wireless antenna set (includes 2 transceivers and cables)
486778-001 WWAN wireless antenna set (includes 2 transceivers and cables)
486782-001 120-GB, 7200-rpm hard drive (includes hard drive bracket)
487330-001 Broadcom 4322 802.11a/b/g/n WLAN module for use in Antigua and Barbuda, Barbados, Belize, Canada,
the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands,
and the United States
36 Chapter 3 Illustrated parts catalog
