Spare part
number
Description
490811-002 Broadcom BCM4312 802.11b/g WLAN module for use in Afghanistan, Albania, Algeria, Andorra, Angola,
Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain,
Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina,
Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde,
the Central African Republic, Chad, Chile, the People's Republic of China, Colombia, Comoros, the Congo,
Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic,
East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France,
French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe,
Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland,
Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia,
Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi,
Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico,
Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal,
the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan,
Palau, Panama, Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal,
the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe,
Saudi Arabia, Senegal, Serbia, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia,
the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis, St. Lucia,
St. Vincent and the Grenadines, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania,
Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine,
the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen,
Zaire, Zambia, and Zimbabwe
491575-001 Modem module for use in all countries and regions except Australia and New Zealand
NOTE: The modem module spare part kits do not include a modem module cable. The modem module
cable is included in the Cable Kit, spare part number 486281-001.
491575-011 Modem module for use only in Australia and New Zealand
NOTE: The modem module spare part kits do not include a modem module cable. The modem module
cable is included in the Cable Kit, spare part number 486281-001.
492161-001 14.1-inch WXGA display assembly with 2 microphones and webcam for use only with HP Compaq 6535b
computer models equipped with both WLAN and WWAN modules
492162-001 14.1-inch WXGA display assembly with 1 microphone for use only with HP Compaq 6535b computer models
equipped with WLAN and WWAN modules
492163-001 14.1-inch WXGA display assembly with 2 microphones and webcam for use only with HP Compaq 6535b
computer models equipped with WLAN modules
492164-001 14.1-inch WXGA display assembly with 1 microphone for use only with HP Compaq 6535b computer models
equipped with a WLAN module and no WWAN module
492165-001 14.1-inch WXGA+ display assembly with 2 microphones and webcam for use only with HP Compaq 6535b
computer models equipped with both WLAN and WWAN modules
492166-001 14.1-inch WXGA+ display assembly with 1 microphone for use only with HP Compaq 6535b computer models
equipped with WLAN and WWAN modules
492167-001 14.1-inch WXGA+ display assembly with 2 microphones and webcam for use only with HP Compaq 6535b
computer models equipped with WLAN modules
492168-001 14.1-inch WXGA+ display assembly with 1 microphone for use only with HP Compaq 6535b computer models
equipped with a WLAN module and no WWAN module
492169-001 14.1-inch WXGA BrightView display assembly with 2 microphones and webcam for use only with
HP Compaq 6535b computer models equipped with both WLAN and WWAN modules
492170-001 14.1-inch WXGA BrightView display assembly with 1 microphone for use only with HP Compaq 6535b
computer models equipped with both WLAN and WWAN modules
38 Chapter 3 Illustrated parts catalog

Compaq 6530b - Notebook PC Specifications

General

Processor	Intel Core 2 Duo
Graphics	Intel GMA 4500MHD
Operating System	Windows Vista Business
Battery Life	Up to 4 hours
Display	14.1-inch WXGA (1280x800)
Memory	Up to 4GB DDR2
Storage	120 GB to 250 GB 5400 rpm SATA
Battery	6-cell Lithium-Ion
Chipset	Mobile Intel GM45 Express
Optical Drive	DVD+/-RW SuperMulti with Double Layer
Networking	Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
Wireless	802.11a/b/g/n
Audio	High Definition Audio, stereo speakers
Ports	VGA, RJ-45
Slots	ExpressCard/54
Processor Speed	2.53 GHz
